Description of products
High Mast Lighting Poles can generally be divided into either a lifting type or non-lifting type. The height of the lifting type pole is normally more than 18 meters and allows for the raising and lowering of the lighting fixture. This allows for a safer and more convenient process of maintenance. The lighting fixture can be lowered up to 2.5 meters from the ground and the lowering process is controlled via a manual remote control. Our high mast poles are available in a wide variety of configurations and finishes to meet your specific design requirements. This includes the shape and lighting fixtures depending on lighting requirements of the surrounding area.
products specification details
l Light Source: High Pressure Sodium Lamp and LED flood light.
l Pole Height: 15 to 40 meters (designed and manufactured according to customer requirements).
l Lighting Type: Circular Light Plate / Irregular Light Plate, Wide-Angled Lights
l Pole Shape: Conical, Polygonal, Round
l Lifting System: Automatic/Manual Lifting System as per client’s requirement
| Material | ASTM GR65,GR50,Q460 A572,S355,Q345/Q235 |
| Design Wind | Depending on clients requirements |
| Lamp Crown Shape | Round,Triangular |
| Pole’s shape | Conical, Polygonal, Round |
| Application | Areas that require a large area of lighting (airports, shipping terminals, stadiums, heavy-industry zones) |
| Height | 15-40M composed of two or three sections |
| Pole Shaft Thickness | 2.5mm-14mm |
| Surface treatment | Hot Dip Galvanization, Electrostatic Spray |
| Components | Lighting Fixture, Lamps, Pole, Electrical Components for Lifting System |
| Lamp Fixture Design | According to lighting requirements of the surrounding area |
| Lamp Fixture | LED,HID,HPS Etc |
| Welding standard | Advanced Submerged Arc Welding technology in accordance with BS EN15614 standards |
| Galvanization Thickness | 80-100 microns on average according to BS EN ISO1461 standards |
| Lifting System Accessories | Stainless Steel rope,Electric Winch etc. |
Production Process
Verification of Materials → Cutting → Molding or Bending → Vertical Welding → Verification of Dimensions → Flange Welding →
Hole Drilling → Calibration → Deburring Process → Galvanizing, Powder Coating or Painting → Recalibration → Threading → Packaging
Product Details
Testing
Packaging & Shipping
We pack the top and bottom parts of the pole with a mat or straw bale in order to protect it from damage to the galvanized surface that may
occur during transportation.
Packaging can also be done according to clients’ requirements.
We can ship the poles by sea or air or express or trains and we have our regular shipping agent.
Export Market
Asia-Pacific, Central & South America,North America, Europe, Middle East, Africa
